DVBT235HMR
DVBT235HMR
| Product Type | Stationary DVB-T set top box |
| Tuner & channel | PRF input connector: 1x (IEC-type, IEC169-2, female) |
| Receiving channel range: 174~230MHz, 470~862MHz | |
| RF output (loopthrough): Yes | |
| Modulation: QPSK/16QAM/64QAM | |
| OFDM Spectrum: 2K and 8K | |
| Band Width: 7MHz, 8MHz | |
| Decoding | Video decoder: MPEG4 AVC/H.264 HP@L4, MPEG-2 |
| Audio decoder: AAC/AC3/PCM | |
| Video output ratio: 16:9/ 4:3 /Auto | |
| Video resolution: 1920×1080 |
| Product Type | Stationary DVB-T set top box |
| Tuner & channel | PRF input connector: 1x (IEC-type, IEC169-2, female) |
| Receiving channel range: 174~230MHz, 470~862MHz | |
| RF output (loopthrough): Yes | |
| Modulation: QPSK/16QAM/64QAM | |
| OFDM Spectrum: 2K and 8K | |
| Band Width: 7MHz, 8MHz | |
| Decoding | Video decoder: MPEG4 AVC/H.264 HP@L4, MPEG-2 |
| Audio decoder: AAC/AC3/PCM | |
| Video output ratio: 16:9/ 4:3 /Auto | |
| Video resolution: 1920×1080 | |
| Function | OSD language: Multi languages |
| Media playback: MP3, JPEG | |
| Record through USB HDD: Yes | |
| Timeshift through USB HDD: Yes | |
| DVB subtitle: Yes | |
| Teletext: VBI/OSD | |
| Channel search with automatic / manual: Yes | |
| Favorite list editing for both radio and TV: Yes | |
| Parents lock: Yes | |
| Timer setting: Yes | |
| Logical Channel Numbering (LCN): Yes | |
| Front panel | Display type: 2 color LED |
| Infra-red receiver: Yes | |
| Function buttons: Yes | |
| Power indicator (LED): Yes | |
| Terminal | Main power cable: Fixed type |
| Tuner: RF input x1, RF loop through x1 | |
| L/R audio output: Yes | |
| CVBS video output: Yes | |
| S-Video Output: Yes | |
| Scart: TV x1 | |
| Y Cb/Pb Cr/Pr(Component): Yes | |
| HDMI: (576P/720P/1080i) Output x 1 | |
| SPDIF: Coaxial x1 | |
| Data port: USB 2.0 x1 | |
| Power supply | Input voltage: AC100/240V, 50/60Hz |
| Power consumption: Max. 8W | |
| Dimensions (L x W x H) ; weight | 235 x 122 x 36 mm , 600g |
| Accessories | Remote control, user guide |
| Color | Black |
